Food & Additives&Feed Processing Solutions：Helping You Achieve Food Safety, Quality, and More Sales
Product Applications
-
Mayonnaise
-
Ketchup Sauce
-
Mustard Sauce
-
Salad Sauce
-
Food pastes
-
Baby food
-
Flavourings
-
peanut butter
-
Chocolate
-
Cheese sauce
-
Animal feed
Product Introduction
- Suitable for manufacturing food emulsions with a wide range of viscosity, such as mayonnaise, salad dressings, sauces, tomato sauce, bread sauce, and chocolate sauce.
- Programmable parameters: can produce a variety of food materials
- Shorter batch time: able to quickly establish a dispersed emulsification system and quickly mix a large amount of powder
- Lower investment cost: Shorten cleaning time and reduce maintenance requirements, optimize and streamline costs to achieve high production.
Working Principle
- The production raw materials are directly pumped into the homogenization head through vacuum, emulsified, and then enter the main tank through a circulating pipeline, and wait to enter the homogenization head again.
- The specially designed scraping wall mixing ensures the mixing effect and high heat exchange efficiency.
Product Description
Standard design
- Main tank with safety device and scraping wall mixing
- Powerful vacuum system
- Homogenizing head with built-in pumping function
- Double layer jacket
- temperature control
- User friendly interface/visualization
- External circulation pipeline
- Automatic cleaning of CIP
- High opening height
Optional
- Shaft sealing ring or mechanical sealing system
- Steam through rapid heating
- Automatic lifting of the top cover
- Three levels of automation and multiple functional modules
- Weighing and measurement
- External circulation pump is used to add particulate matter (vegetable granules, fruit granules, etc.)
- Small circulation
- Other customization options according to your needs
Specifications
|
Model |
Design volume(L) | Max. Useful volume (L) | Min. Useful volume(L) | Dimensions (L*W*H/mm) |
| MC-H-15 | 15 | 12 | 3 |
1400*900*1600(1650) |
|
MC-H-50 |
50 | 40 | 10 | 1400*1500*1800(2100) |
| MC-H-150 | 150 | 120 | 30 |
1600*1500*2100(2250) |
|
MC-H-350 |
350 | 280 | 70 | 2000*1750*2300(2500) |
| MC-H-650 | 620 | 500 | 130 |
2300*1900*2700(2900) |
|
MC-H-1300 |
1300 | 1000 | 260 | 3000*2100*3100 |
| MC-H-2500 | 2500 | 2000 | 500 |
3100*2300*3700 |
|
MC-V-30 |
30 | 25 | 6 | 1250*1050*1700(2050) |
| MC-V-100 | 100 | 80 | 20 |
1400*1200*2200(2700) |
|
MC-V-250 |
250 | 200 | 50 | 1900*1500*2700(3400) |
| MC-V-650 | 650 | 500 | 130 |
2400*1800*3000(3900) |
|
MC-V-1300 |
1300 | 1000 | 260 | 2500*2000*3600(4800) |
| MC-V-2500 | 2500 | 2000 | 500 |
3000*2000*4000(5000) |
Some Cases Show
