high shear mixer
  • Electric lifting structure, stable parking at any position

Optional heating and temperature control device.

Brief Introduction

LR-5 high shear mixer series is the most popular machine in our laboratory mixer series. It is the ideal choice for routine laboratory work, R&D, QA analysis and small-scale production in all industries.

LR-5 high shear mixer series has a wide range of industrial applicability, through the replacement of stator and rotor, it can easily achieve mixing, homogenization, emulsification, dispersion, dissolution and other functions, which is incomparable with other similar equipment efficiency and flexibility. In addition, the LR-5 high shear mixer series is equipped with special on-line hybrid modifications, which can provide experimental data for large-scale continuous production.

Core Advantage

  • All SUS304 food-grade stainless steel shell, corrosion-resistant, easy to clean, easy to handle.
  • With servo motor, the speed can be adjusted arbitrarily in the range of 600-8000rpm, and with feedback device, the speed is stable and reliable, which can be used for reference in enlarging production.
  • It can run continuously for more than 2 hours at full load to meet all kinds of rigorous experimental requirements.
  • Various stator and rotor structures can be interchanged quickly to meet different
structure of high shear mixer

1. Timing knob



The timer of 0-30 minutes, 40mm aluminium alloy knob, anti-skid surface treatment, even wearing gloves can be accurately adjusted.

2. Speed control knob

600-8000 rotational speed regulation, 40mm aluminum alloy knob, surface anti-skid treatment, even wearing gloves can be accurately adjusted.

3. Mean Start Button





Stainless steel self-locking button, excellent feedback experience, corrosion resistance, easy to clean.

4. High shear mean working head



Stainless steel self-locking button, excellent feedback experience, corrosion resistance, easy to clean.

5. Stainless steel bracket

SUS304 material pallet, can be quickly disassembled, easy to flush sticky materials, and pallet can be optionally replaced by heating module.

6. Lifting column





SUS304 material, can dock at any position

7. All Stainless Steel Material

The whole mechanism and shell are made of SUS304 material of food grade, which is beautiful, sanitary, corrosion-resistant and easy to clean.

8. Cooling Fan



With the top ventilation hole to form a complete duct to ensure the stable operation of homogeneous motor components.

9. Rubber foot



It has the function of anti-skid and shock absorption.

10. Lift button

Stainless steel push button, excellent experience of operation feedback, corrosion resistance, easy to clean.

11. Power Supply

220V single-phase connection with power supply indication, cut off switch and fuse

12. Fin type radiator

Make sure the parts in the cabinet of ventilation and cooling, prolong the service life of electrical parts.

The standard variety of working head, to meet the needs of all kinds of work.

4kinds of Homogeneous Stator

Type A Universal Homogeneous Stator



Homogeneous stator with wide application is suitable for mixing and dispersing occasions. For example, dispersion of solid and liquid, dissolution of gel and thickener, preparation of suspension and slurry.

Type B Slot Homogeneous Stator



It has moderate homogenization performance and can be used in various occasions where homogenization is required. It can also be used for crushing and dissolving of fiber materials and various polymers.

Type C Pass Homogeneous Stator









It is suitable for homogenization and emulsification of liquid and liquid, and is especially suitable for preparing all kinds of emulsions.

Type D Axial Homogeneous Stator



The special homogeneous stator can change the homogeneous jet flow into a bottom-up axial jet. It is very suitable for the conditions that need to reduce bubbles and maintain a constant cycle of heavy insoluble solids.

high shear mixer size

Technical data.

Model LR-5 Knob style Digital display
Min. Working Capacity(ml)

300

Max. Working Capacity(ml)

5000

Total Power(w)

800

Highest Speed(rpm)

8000

Power Supply

220V 50Hz

Length(mm)

505

Width(mm)

340

Lowering Height(mm)

720

Lifting Height(mm)

1010

Special Function Longest time setting: 30min Rotating speed is displayed
