With mature structural design, sanitary manufacturing standard and stable high shear homogenizing system, it is widely used in cosmetics, pharmaceutical, food and daily chemical mass production, delivering stable and excellent emulsification quality.
SP Series
Standard Vacuum Processing Unit
Reliable, Hygienic, High-Performance Emulsification for Industrial Production
SP Series Structural Composition
2 Stirring Types + 2 Homogenizing Types
Through different combinations of stirring structure and homogenizing structure,
SP series forms four classic configurations to cover different viscosity and production demands.
Single Shaft Unidirectional Ribbon Stirring
Compact structure, stable running and low energy consumption.
Single Shaft Unidirectional Ribbon Stirring
Realize overall circulating turnover of conventional materials, uniform mixing efficiency, suitable for general low and medium viscosity products and conventional mass production.
Bidirectional Counter-Rotating Stirring
Adopt inner and outer double-layer counter stirring design.
Bidirectional Counter-Rotating Stirring
Strong material turning ability, effectively avoid material accumulation and mixing dead angle. Great for medium and high viscosity materials to ensure full mixing and balanced temperature transfer.
Internal Bottom Homogenizer
Built-in bottom high-shear homogenizing head, integrated installation, compact layout.
Internal Bottom Homogenizer
Internal bottom homogenizer convenient daily maintenance, stable basic shearing and emulsifying capacity, cost-effective for standard production formulas.
External Circulation Homogenizer
Independent external circulation homogenizing system, enhanced high shear effect.
External Circulation Homogenizer
Realize forced external circulation of materials, finer particle dispersion and more delicate product texture. Ideal for products requiring higher emulsification fineness and stability.
4 Classic Configurations of SP Series
Combined by 2 stirring modes and 2 homogenizing modes, to match different production needs：
① SPA-Ⅰ：Single Stirring + Internal Homogenizer
Cost-effective basic model, simple structure and stable operation.
Suitable for conventional low & medium viscosity materials, daily chemicals, common creams and lotions mass production.
② SPA-Ⅱ：Single Stirring + External Circulation Homogenizer
On the basis of single stirring, upgrade to external circulating homogenization.
Better shearing and fineness, suitable for products that need improved uniformity and fine texture.
③ SPB-Ⅰ：Bidirectional Stirring + Internal Homogenizer
Bidirectional counter stirring with built-in bottom homogenizer.
Strong mixing performance for high viscosity materials, solving poor turnover of thick paste materials.
④ SPB-Ⅱ：Bidirectional Stirring + External Circulation Homogenizer
High-end full-function configuration.
Dual stirring + external high shear circulation, comprehensive mixing and emulsifying capacity, strong formula adaptability, for high viscosity and high-demand emulsification production.
Technical Parameters
|
Model |
Design Volume（L） | Max. Work Volume（L） | Min. Work Volume（L） |
Dimens（mm） |
|
SPA-650 |
650 | 520 | 110 | 1250*1250*2960 |
|
SPA-1300 |
1300 | 1000 | 200 |
1500*1500*3610 |
|
SPA-2000 |
2000 | 1500 | 350 | 1720*1720*3940 |
|
SPA-3000 |
3000 | 2500 | 500 |
1970*1970*4570 |
|
SPA-4000 |
4000 | 3000 | 650 |
2150*2150*4700 |
|
SPA-5000 |
5000 | 4000 | 800 |
2270*2270*4700 |
|
SPA-6000 |
6000 | 5000 | 1000 |
2270*2270*5220 |
SS316L sanitary upgrade, heating & cooling jacket, PLC automatic control, CIP cleaning system, explosion-proof design and customized accessories.
We provide professional formula selection, drawing support, installation guidance and after-sales service, to guarantee stable and efficient operation for your large-scale production.
Application Industries
On-Site Engineering & Project Cases
SP series emulsifiers have been widely installed and operated in many domestic and overseas manufacturing workshops, covering personal care, pharmaceutical preparations, food condiments and fine chemical industries.
SPB-Ⅱ：Bidirectional Stirring + External Circulation Homogenizer
For food industry
SPA-Ⅰ：Single Stirring + Internal Homogenizer
For cosmetics
SPA-Ⅱ：Single Stirring + External Circulation Homogenizer
For pharmaceutical
Our Strength & On-Site Production
The image above shows a real on-site photo of our SP Series emulsifier in our production workshop.
With nearly 30 years of experience in the design and manufacturing of industrial emulsifying equipment, we have accumulated extensive professional expertise and reliable technical capabilities to support your production across cosmetics, pharmaceuticals, food, daily chemicals and other fine chemical industries.
We understand that each customer may face unique challenges in actual production, such as formula compatibility, texture optimization, production efficiency improvement, and compliance with hygiene and safety standards.
Our professional team, backed by decades of practical experience, is able to provide targeted solutions tailored to your process, helping you resolve on-site difficulties, stabilize product quality, and ensure smooth, reliable large-scale production.
